MSI X870E Gaming Plus (Wi-Fi) DDR5 Motherboard

Specifications

CHIPSET

AMD X870

CPU

Supports AMD Ryzen™ 9000/ 8000/ 7000 Series Desktop Processors Socket AM5

MEMORY

4x DDR5 UDIMM, Maximum Memory Capacity 256GB

Memory Support DDR5 8200 - 5600 (OC) MT/s / 5600 - 4800 (JEDEC) MT/s

max. overclocking frequency

1DPC 1R Max speed up to 8200+ MT/s

1DPC 2R Max speed up to 6400+ MT/s

2DPC 1R Max speed up to 6400+ MT/s

2DPC 2R Max speed up to 6000+ MT/s

ONBOARD GRAPHICS

1x HDMI™ Support HDMITM 2.1, maximum resolution of 4K 60Hz* 1x Type-C DisplayPort USB4® port, supporting DisplayPort 1.4 with HBR3 over USB Type-C, maximum resolution of 4K 60Hz* *Available only on processors featuring integrated graphics. Graphics specifications may vary depending on the CPU installed.

SLOT

3x PCI-E x16 slot

1x PCI-E x1 slot

PCI_E1 Gen PCIe 5.0 supports up to x16 (From CPU)

PCI_E2 Gen PCIe 3.0 supports up to x1 (From Chipset)

PCI_E3 Gen PCIe 4.0 supports up to x4 (From Chipset)

PCI_E4 Gen PCIe 3.0 supports up to x1 (From Chipset)

AUDIO

Realtek® ALC897

7.1-Channel High Definition Audio

STORAGE

3x M.2

RAID

••Supports RAID 0, RAID 1 and RAID 5 for M.2 NVMe storage devices *SATA_A1~A4 do not support RAID function. *RAID 5 configuration is only supported by Ryzen™ 9000 series processors.

USB

4x USB 2.0 (Rear) , 6x USB 2.0 (Front)

2x USB 5Gbps Type A (Rear) , 4x USB 5Gbps Type A (Front)

2x USB 10Gbps Type A (Rear) , 1x USB 10Gbps Type C (Front)

1x USB 20Gbps Type C (Rear) , 1x USB 40Gbps Type C (Rear)

LAN

Realtek® 8126VB 5G LAN

INTERNAL IO

1x Power Connector(ATX_PWR),2x Power Connector(CPU_PWR),1x Power Connector(PCIE_PWR 8pin)

1x CPU Fan,1x Combo Fan (Pump_Sys Fan),6x System Fan,1x EZ Conn-header (JAF_1)

2x Front Panel (JFP),1x Chassis Intrusion (JCI),1x Front Audio (JAUD)

1x Tuning Controller connector(JDASH),3x Addressable V2 RGB LED connector (JARGB_V2)

1x RGB LED connector(JRGB),1x TPM pin header(Support TPM 2.0)

6x USB 2.0 ports,4x USB 5Gbps Type A ports,1x USB 10Gbps Type C ports

WIRELESS LAN & BLUETOOTH

Wi-Fi 7

LED FEATURE

4x EZ Debug LED

1x EZ Memory Detection LED

OPERATING SYSTEM

Support for Windows® 11 64-bit

PCB INFO

ATX | 243.84mmx304.8mm

WARRANTY

03 YEARS WARRANTY
