MSI MAG X870E Tomahawk (WIFI) DDR5 Motherboard

Specifications

Prices may vary daily due to chip allocation for AI as well as global stock issues. Therefore, please check prices before placing an order by contacting our hotline.(+94 777 22 33 63)

CHIPSET

AMD X870E

CPU

Supports AMD Ryzen™ 9000 / 8000 / 7000 Series Desktop Processors (AM5 socket)

MEMORY

4x DDR5 UDIMM, Maximum Memory Capacity 256GB

Memory Support DDR5 8400 - 5600 (OC) MT/s / 5600 - 4800 (JEDEC) MT/s

Max. overclocking frequency:

• 1DPC 1R Max speed up to 8400+ MT/s

• 1DPC 2R Max speed up to 6400+ MT/s

• 2DPC 1R Max speed up to 6400+ MT/s

• 2DPC 2R Max speed up to 4800+ MT/s

ONBOARD GRAPHICS

1x HDMI™ Support HDMI™ 2.1 FRL, maximum resolution of 8K 60Hz

2x Type-C DisplayPort USB4® port, supporting DisplayPort 1.4 with HBR3 over USB Type-C, maximum resolution of 4K 60Hz

SLOT

3x PCI-E x16 slot

PCI_E1 Gen PCIe 5.0 supports up to x16 (From CPU)

PCI_E2 Gen PCIe 3.0 supports up to x1 (From Chipset)

PCI_E3 Gen PCIe 4.0 supports up to x4 (From Chipset)

AUDIO

Realtek® ALC4080 Codec, 7.1-Channel High Performance Audio, 2x 3.5mm jacks, Optical S/PDIF

STORAGE

4x M.2 slots (2x PCIe 5.0 x4 from CPU, 2x PCIe 4.0 x4)

RAID

Supports RAID 0, 1, 5, 10 for M.2 NVMe storage devices

USB

4x USB 2.0 (Rear)

4x USB 2.0 (Front)

3x USB 5Gbps Type A (Rear)

4x USB 5Gbps Type A (Front)

2x USB 10Gbps Type A (Rear)

1x USB 10Gbps Type C (Rear)

1x USB 20Gbps Type C (Front)

2x USB 40Gbps Type C (Rear)

LAN

1x Realtek® 8126 5G LAN

INTERNAL IO

1x Power Connector(ATX_PWR),2x Power Connector(CPU_PWR),1x Power Connector(PCIE_PWR 8pin)

1x CPU Fan,1x Combo Fan (Pump_Sys Fan),6x System Fan,1x EZ Conn-header (JAF_2)

2x Front Panel (JFP),1x Chassis Intrusion (JCI),1x Front Audio (JAUD)

3x Addressable V2 RGB LED connector (JARGB_V2),1x RGB LED connector(JRGB)

1x TPM pin header(Support TPM 2.0),4x USB 2.0 ports,4x USB 5Gbps Type A ports,1x USB 20Gbps Type C ports

LED FEATURE

4x EZ Debug LED

1x EZ Digit Debug LED

OPERATING SYSTEM

Windows 11 64-bit required for full features ​

PCB INFO

ATX | 243.84mmx304.8mm

WARRANTY

3 Years Warranty
